    192kw Hydraulic Heavy Equipment Power Excavator High Efficiency

    Ask Lasest Price
    Brand Name : Visbull
    Model Number : SC330.8
    Certification : Ghost/ISO/SGS/CE
    Price : negotiation
    Payment Terms : Western Union, L/C, T/T
    Supply Ability : 1000 units per month
    Delivery Time : 10 working days after received L/C or your deposit
    • Product Details
    • Company Profile

    192kw Hydraulic Heavy Equipment Power Excavator High Efficiency

    192kw Hydraulic Heavy Equipment Power Excavator High Efficiency


    Based on the market research, 33-ton excavator is independently developed with the technology advantages. Featuring excellent economy, comfortability, safety and reliability, the excavator adopts Cummins engine, which is 260 powerhouse strong power and economy, saving 15%-20% fuel. The excavator adopts famous brand of hydraulic system in the world; the computer monitor of reliable performance can judge the working condition of the machine. With the bucket of 1.4-1.6 m3, the working amount can be improved by 17-30%, therefore the efficiency is increased. With the installed cab protective rail, the operator gets the safe and comfortable operation environment.

    ItemUnitReference value
    Engine
    ModelCUMMINS 6CTA8.3
    BatteryV,Ah24,120×2
    AlternatorA24V 70
    Rated output powerKw/rpm192/2000
    Piston displacementL8.3
    Cylinder no. (bore×stroke)mm6-φ114×135
    Type4 strokes, water cooling, in-line, direct injection, turbo charged
    Working device
    Boom lengthmm6470
    Bucketm31.6 light load type(option)
    Bucketm31.2 rock type (option)
    Bucketm31.4 Standard type
    Arm lengthmm3185
    Travel part
    Carrying wheel2 in both sides
    Track board45 in each side
    Supporting wheel7 in each side
    Hydraulic system
    Hydraulic pump typevariable displacement pump
    Bucket cylinder
    Cylinder bore (mm)×piston rod diameter (mm)
    φ140×φ100
    Arm cylinder(mm)×piston rod diameter(mm)φ170×φ120
    Boom cylinder(mm)×piston rod diameter(mm)mmφ140×φ100
    Rotary motorAxial piston type (with safety valve and parking brake)×1
    Travel motorAxial piston type (with brake valve and parking brake)×2
    Control valve control methodHydraulic pilot
    Control valve typeKMX15R
    Hydraulic pump set pressureMPa (kg/cm2)34.3(350)

    A Overall length mm11080
    A1 Grounding length mm5720
    B Overall width mm2995
    C Overall height mm3180
    D Machine body height mm3278
    E Clearance of super structure mm1208
    F Min clearance mm498
    G Rear slewing radius mm3418
    H Track grounding length mm3700
    J Track length mm4622
    K Track gauge mm2390
    L Track width mm3190
    M Standard track board width mm600
    V Min. slewing radius of working device mm4265
    X Distance from slewing center to rear mm3418
    O Max. digging height mm10200
    P Max. dumping height mm7135
    Q Max. digging depth mm7370
    R Max. vertical digging depth mm6380
    T Max. digging radius mm11100
    U Max. digging radius mm10910
    W Height for min. slewing radius mm8500
    Max. bucket digging force KN248
    Slewing speed rpm10.6
    Travel speed km/hL:3.2/H:5.2
    Grounding pressure kPa60.8
