    Deutz 150KW Diesel Asphalt Paver Machine , 9.0m XCMG Concrete Road Paving Equipment

    Ask Lasest Price
    Brand Name : Visbull
    Model Number : RP903
    Certification : CE/SGS
    Price : Negotiation
    Payment Terms : D/A, L/C, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 500pcs per month
    Delivery Time : 25-30working days after received your payment
    • Product Details
    • Company Profile

    Deutz 150KW Diesel Asphalt Paver Machine , 9.0m XCMG Concrete Road Paving Equipment

    Deutz 150KW Diesel Asphalt Paver Machine , 9.0m XCMG Concrete Road Paving Equipment


    9.0m XCMG Multi - Function Asphalt Concrete Paver RP903 With 15 Tons Hopper Capacity And Deutz 150KW Diesel Engine9m XCMG Multi - Function Asphalt Concrete Paver RP903

    Specifications:


    ltem

    Unit

    Parameter

    Theoretical productivity

    t/h

    800

    Max working Width

    m

    9.0

    Max Paving Thickness

    mm

    300

    Paving Speed

    m/min

    0~18

    Flatness

    mm/3m

    1.2

    Compactness

    %

    ≥90

    Dense irregularity

    %

    <4

    Traveling Speed

    km/h

    2.8

    Drive type


    Crawler

    Gradient Ability

    %

    20

    Hopper Capacity

    t

    15

    Hopper Width

    mm

    3450

    Hopper Length

    mm

    2595

    Engine Type


    BF6M1013ECP

    Rated Output

    KW

    150

    Speed

    rpm

    2000

    Fuel Tank Capacity

    L

    300

    Weight

    t

    24.5~28.5

    Overall Dimension

    mm

    7290×2600×3950


    RP903 asphalt paver has excellent performance, high cost, good economy and adaptability, novel

    appearance, is a widely used in various construction equipment class road surface paving job.


    1, Good Working Conditions Adapt


    1) The newly designed hydraulic telescopic screed device can quickly adapt to different road conditions;

    2) The optimal design by feeding system, to adapt to the needs of different skip;


    2, Stable Operating Performance


    1) Electronic control system imported controller and self-developed control software, advanced

    technology, stable performance;

    2) High-end configuration 9 meters large-scale hydraulic telescopic screed means paving high quality,

    stable operating performance;

    3) Large ground area of the crawler traction, stable running performance;e optimal design by feeding

    system, to adapt to the needs of different skip;


    3, Comfortable Experience


    1) All the parts are to be detected in the fingertips installation, inspection, easy maintenance;

    2) Machine accessory fast connections, convenient;

    3) the use of ergonomics and noise reduction design, has good man machine interface and comfortable

    operating experience, all parts are to be detected in the fingertips installation, inspection, easy

    maintenance;

    4) Configure the hard left and right extendable roof, hydraulic power lift, ease of operation;


    4, High-quality Components Configuration


    1) The key element of the hydraulic pump, motor, reducer, solenoid valves, etc., with international brands;

    2) conveying floor screed floor imported wear resistant steel, durable;
