    Direct Injection Diesel Engine ZL20F Wheel Loader for Urban Construction / Agricultural Engineering

    Ask Lasest Price
    Brand Name : Visbull
    Model Number : ZL20F
    Certification : CE/EMARK/GHOST/ISO
    Price : negotiation
    Payment Terms : L/C at sight, T/T or western Union
    Supply Ability : 1200 units per month
    Delivery Time : 10 working days after received L/C or your deposit
    • Product Details
    • Company Profile

    Direct Injection Diesel Engine ZL20F Wheel Loader for Urban Construction / Agricultural Engineering

    Direct Injection Diesel Engine ZL20F Wheel Loader for Urban Construction / Agricultural Engineering


    2000 kg capacity 1.2M3 Bucket 4WD mini Wheel Loader ZL20F with new hood


    Feature:

    1. Using direct injection diesel engine as power, with easy startup and low oil consumption
    2. Using special drive axle, with strong ability to overcome obstacle
    3. Chassis uses hinged structure, with small turning radius and flexible turning, which applies to the operation in narrow space
    4. This machine uses hydraulic operation, with simple structure, convenient operation, good performance and reliable quality
    5. Widely applying to the construction of agricultural engineering and small and medium building such as road, coal mine, brickyard, urban construction, kiln factory, stone material factory, prefabricated cement parts factory, etc.


    Specification

    Rated bucket capacity

    1.2M3

    Rated loading weight

    2000kgs

    Operating weight

    5310kgs

    Auto. self-leveling system

    Have

    Rated loading turn force

    4000kgf

    Max. breakout force

    5467kgf

    Max. pulling force

    45.4kN

    Grade ability

    30 degree

    Lifting time of arm

    5.9s (full load)

    Lowering time of arm

    2.8s (full load)

    Tilting time of arm

    1.1s

    Overall dimension

    5630x2100x2850mm

    Engine

    Model

    4DX21-72

    Type

    Water cooled, 4-strokes

    Bore x Stroke

    105x125mm

    Max. torque

    270Nm

    Rated power

    55kW

    Min. oil consumption

    ≦ 243g/ kw.h

    Rated speed

    2200rpm

    Transmission system


    Torque converter model

    YJ-280A

    Type

    Single phase, 3-elements

    Gearbox type

    Fixed shaft power shift

    Shifts (forward/reveres)

    2/2

    Max. traveling speed

    24km/hour

    Tire


    Size

    16/70-20

    Front wheel pressure

    220kps

    Rear wheel pressure

    180kps

    Steering system


    Steering angle

    ± 35degrees

    Mini. Steering radius

    5251mm

    Others


    Dumping clearance

    2600mm

    Dumping reach

    752mm

    Min. Ground clearance

    310mm

    Wheel base

    2400mm

    Wheel tread

    1640mm

    Max. bucket reach

    4092mm
