    3M Lifting Height 4 Ton Industrial Forklift Truck for Loading Transportation

    Ask Lasest Price
    Brand Name : Visbull
    Model Number : CPCD40
    Certification : ISO / CE
    Price : negotiation
    Payment Terms : L/C at sight, T/T or western Union
    Supply Ability : 1500 units per month
    Delivery Time : 15 working days after received L/C or your deposit
    • Product Details
    • Company Profile

    3M Lifting Height 4 Ton Industrial Forklift Truck for Loading Transportation

    3M Lifting Height 4 Ton Industrial Forklift Truck for Loading Transportation


    3M Lifting Height 4Ton Diesel Forklift Truck CPCD40 With 5100Kg Operating Weight And 2720MM Min Turning Radius


    Description:

    1. Full automatic stepless speed adjustable electric controlled transmission gear box guarantee the forklift with superior travel and track performance.

    2. New type engine with super power has features of good performance , low fuel consumption, enough power reservation ,EPA standard displacement level.

    3. Advanced hydraulic system, 2-speed lifting system can automatically adjust its lifting speed according to the goods weight ,electric controlled valve can work safety and efficiently.

    4. Eqiupment with heavy –duty driving axle with big bearing capacity and enhanced oil cooled braking system, increase the reliabillgy and durability.

    5. Equipments with fine safety monitor to make it has clear visibility, 3-step switch-lock confirmation device to guarantee safe work.

    6.Centralize controlled lever and stimulant automatic instrument is easy operated and has beautiful appearance.

    7. high strength mast of CJ shape welded by refined steel, has features of high strength and rigid.Sweden "H" typed ELME spreader up to advanced international level, enhance its operation and reliability.

    8. New cabin has comfort windows and wide view, with air conditioner can modify the operative circumstance.

    9. The whole truck has advanced technology, beautiful, appearance, reasonable layout, is the best new model.


    Specifications:

    Model

    Unit

    CPCD40

    CPCD45

    Power type

    Diesel

    Rated capacity

    kg

    4000

    4500

    Load center

    mm

    500

    Mast Lifting height

    mm

    3000

    Free lift height

    mm

    150

    Fork size(L*W*T)

    mm

    1070×150×50

    Tilting Angles(Front/Rear)

    deg

    6°/12°

    Front overhang

    mm

    490

    545



    Exterior Size

    Length without fork

    mm

    2885

    2900

    Overall width

    mm

    1480

    Mast drop

    mm

    2230

    Max.lift

    mm

    4200

    Front-wheel Overhead

    mm

    2300

    Min Turning Radius

    mm

    2720

    2740

    Min.intersecting aisle

    mm

    3345

    3365



    Speeds

    Max Driving speeds

    km/h

    19.5/20

    19/21

    Lifting speeds

    mm/s

    470/520

    500/530

    Lowering speeds

    mm/s

    ≤600

    Max.grade ability

    %

    25/20

    27/20

    Total weight

    kg

    5100

    6400


    Tires

    Front

    250-15-16PR

    300-15-18PR

    Rear

    6.50-10-10PR

    7.00-12-12PR

    Wheelbase

    mm

    1900

    2000


    Tread

    Front

    mm

    1160

    1180

    Rear

    mm

    1065

    1190

    Min. ground clearance

    mm

    145

    155



    Engine

    Model

    Isuzu 4JG2 Engine

    Isuzu 6BG1 Engine

    Rated output

    kw/rpm

    37/2650

    59/2400

    Rated torque

    N.m/rpm

    148/1800

    288/1600

    No.of cylinder

    4

    Displacement

    L

    3.17

    4.33

    Fuel tank capacity

    L

    65

    95


    Main Features:


    LCD Dashboard

    Our exquisite dashboard can present clear display, elegant looking & practical meter function

    Streamlined Counter Weight

    The simplified streamlined design can ensure both graceful appearance & swift turning in narrow aisle space

    Smart Steering Wheel
    The smart wheel application has greatly increased easy& efficient operation for drivers

    Wholly Integrated Frame

    Our fully welded frame could enhance safety and overall stability substantially

    Sturdy Mast

    German originally imported Mast steel has tremendously improved its hardness & strength and effectively avoid mast deformation

    Transmission

    By comparison, G.C Power self-innovative transmission possess unique features in minimum vibration, swift response in quick starting & accelerating, easy assemble & maintenance etc

    Hydraulic Steering

    Our fully hydraulic system can guarantee highly precise and smooth steering

    Tough Axle

    Heavy load can be easily lifted by our tough & durable axle
