    16 Meter 2WD Articulated Hydraulic Boom Lift With 230kgs Capacity 180 Return Platform

    Ask Lasest Price
    Brand Name : Visbull
    Model Number : GTZZ16Z
    Certification : CE/ISO9001
    Price : USD49800-USD51000 per unit
    Payment Terms : L/C at sight, T/T . Western Union, MoneyGram
    Supply Ability : 100 units per month
    Delivery Time : 30 working days after received your deposit
    • Product Details
    • Company Profile

    16 Meter 2WD Articulated Hydraulic Boom Lift With 230kgs Capacity 180 Return Platform

    16 Meter 2WD Articulated Hydraulic Boom Lift With 230kgs Capacity 180 Return Platform


    Specifications:


    MODEL GTZZ16Z

    MEASUREMENTS

    Metric

    US

    Working height maximum

    17.7m

    58ft

    Platform height maximum

    16m

    52ft6in

    Horizontal reach maximum

    9.5m

    25ft

    A

    Platform length-8ft model

    0.76m

    2ft6in

    C

    Platform width-8ft model

    1.83 m

    6ft

    D

    Height-stowed

    2.38 m

    7ft5in

    E

    Length-stowed

    6.80 m

    22ft3in

    B

    Width

    2.29 m

    7ft5in

    F

    Wheelbase

    2.20 m

    7ft2in

    G

    Ground clearance-center

    430 mm

    1ft4in

    Lift capacity (restricted)

    230kg

    500Ibs

    Platform rotation

    180°

    Turntable Swing

    360°non-continuousss

    Turntable tail swing

    0

    Drive speed -stowed

    6.3 km/h

    3.9mph

    Gradeability -stowed (2WD)

    30%

    Turning radius - inside

    3.0m

    9ft8in

    Turning radius – outside

    5.2m

    17ft

    Controls

    24V DC Proportional

    Solid tires

    33/12-20 D625

    POWER

    Power source

    Cummins B3.3NA-C60 4 60HP (45kw) Perkins 400 61hp (45.5kw)

    Auxiliary power unit

    24V DC

    Hydraulic tank capacity

    113.6L

    Fuel tank capacity

    100L


    2WD

    7657kg


    STANDARDS COMPLIANCE

    EN280,JG/T5101,Q/ADZV001-2008


    Description:

    Our boom lift can be divided into two types, telescopic type and articulating type. Our telescopic boom lift is powered by an internal combustion engine, 4*4 driving mode and 4*2 driving mode are available for you to choose. This type of aerial working platform with a wide operation range, it could be used to handle aerial operation for a variety of rough terrain. Currently it is mainly applied for building construction, bridge building, ship building, outdoor advertisement facility installation, as well as construction of airport, mine, port and more.


    Features:

    1. It is a self-propelled articulated boom lift.
    2. It can realize the lifting upwards, onwards, etc.
    3. The two-wheel and four-wheel driving mode, diesel, electric motor, double power sources, etc. are optional.
    4. The working height ranges from 12m to 26m.
    5. The horizontal reach of the self-propelled articulated boom lift ranges from 7m to 13.3m.
