    Diesel 36M Telescopic Hydraulic Boom Lift for Self Propelled Aerial Work 480KG Load Capacity

    Ask Lasest Price
    Brand Name : Visbull
    Model Number : GTBZ36
    Certification : ISO/CE
    Price : negotiation
    Payment Terms : L/C at sight, T/T . Western Union, MoneyGram
    Supply Ability : 500 units per month
    Delivery Time : 30 working days after received your deposit
    • Product Details
    • Company Profile

    Diesel 36M Telescopic Hydraulic Boom Lift for Self Propelled Aerial Work 480KG Load Capacity

    Diesel 36M Telescopic Hydraulic Boom Lift for Self Propelled Aerial Work 480KG Load Capacity


    Measurements Specifications:

    MODEL

    GTBZ36

    MEASUREMENTS

    Metric

    US

    Working height maximum *

    38.34m

    126ft

    Platform height maximum

    36.64m

    120ft

    Horizontal reach maximum **

    22.9m

    75ft

    Below ground reach

    4.64m

    15ft

    Platform length-8ft model

    0.91m

    3ft

    Platform length-6ft model

    0.76m

    2ft6in

    Platform width-8ft model

    2.44m

    8ft

    Platform width -6ft model

    1.83m

    6ft

    Height-stowed

    3.08m

    10ft

    Length-stowed

    12.96m

    43ft

    Width –axle retracted

    2.49m

    8ft

    Width –axle extended

    3.35m

    11ft

    Wheelbase

    3.66m

    12ft

    Ground clearance-center

    0.43m

    1ft5in

    Lift capacity (restricted)

    480kg

    1056lbs

    Lift capacity (non-restricted)

    340kg

    748lbs

    Platform rotation

    160°

    Jib rotation

    Turntable Swing

    360°continuous

    Turntable tailswing -axle retracted

    1.82m

    6ft

    Turntable tailswing -axle extended

    1.38m

    5ft

    Travel speed -stowed

    4.4km/h

    2.73mph

    Travel speed -raised or extended

    1.1km/h

    0.68mph

    Gradeability -stowed (4WD/2WD)

    42%/30%

    inside

    Turning radius - axle retracted outside

    4.14m

    13ft7in

    6.56m

    22ft

    inside

    Turning radius - axle extendeded outside

    2.74m

    9ft

    5.85m

    19ft

    Controls

    24V DC Proportional

    Solid tires

    12.00-20/8.5

    Power

    Power source

    Lovol 1004-4 78 hp (58kw)

    Perkins 400 76 hp (56kw)

    Cummins B3.3.80 HP (60kw)

    Auxiliary power unit

    24V DC

    Hydraulic tank capacity

    265L

    Fuel tank capacity

    150L

    WEIGHT

    2WD

    20020kg

    44144lbs

    4WD

    20100kg

    44321lbs

    STANDARDS COMPLIANCE EN280,JG/T5101,Q/ADZV001-2008
